Applicable fields
Advertising industry, decoration, furniture, model manufacturing, and handicraft industry. The machine is widely applied in the fine engraving, cutting and hollowing out on nonmetallic materials. With all kinds of characters, graphs, images, trademarks and so on.
Available Materials
Acrylic, organic board, double color plate, plank, bamboo product, paper, glass etc.
Technical Information
|
Technical Index
|
Technical Parameter
|
Memo
(Buyer’s option)
|
|
Model
|
SCU1060
|
|
|
Working platform size
|
1000*600mm
|
|
|
Power
|
Co2 60/80W(Chinese Tube)
|
50W/75W RF laser tube (imported)
|
|
Controlling system
|
USB
|
PCI
|
|
Software
|
DSP
|
|
|
Support format
|
PLT, BMP, DXF, DST, T100, etc
|
|
|
Process Material
|
Non-metal Materials
|
|
|
Cutting speed
|
≤500mm/s
|
The machine can fix servo-motor to improve the movement performance
|
|
Engraving speed
|
≤1000mm/s
|
|
Repeated accuracy
|
≤±0.025mm
|
|
Min. cutting character
|
0.1mm
|
|
Max. cutting depth
|
0-25mm(it’s up to the material)
|
|
|
Cooling ways
|
circulation of water cooling
|
|
|
Working temperature
|
0-35°C
|
|
|
Working humidity
|
5-95%
|
|
|
Working Power
|
220V/50Hz/1kVA
|
|
|
Dimension
|
1670*1450*1280 mm
|
|
|
Net weight
|
399kg
|
|
|
Cubage
|
3.09CMB
|
|
|
Package
|
Standard Crate for export
|
|
|
The whole machine include
|
Air pump
|
|
|
Exhausting Fan
|
|
|
Cooling water box
|
|
|
Other included
|
Accessory box (Including PCI card, Microsoft dog, tools, pipes, quality certification etc.)
|
|
|
Minimum Order Quantity
|
1 Set
|
|
|
Delivery Time
|
3-5 days
|
|
|
Payment Terms
|
T/T
|
|
Would you tell me your demand in details? So that we can help you choose what you want.
1.What materials is to processed normally? What size is the working area?
2.Do you want to engrave or cut mainly? If to cut, how thick is the material?
